UP SQUARED I12

Features

  • 12th/13th Generation Intel® Core™ i7/i5/i3/Celeron® Processor SoC
  • Up to 16GB Onboard LPDDR5
  • Up to 128GB Onboard SSD
  • M.2 2230 E-Key/M.2 2280 M-Key/SATA 6Gb/s x 1
  • 1GbE x 2
  • HDMI 1.4b/DP 1.2 Connector x 1, DP 1.4a via USB Type-C x 1
  • USB 3.2 Gen 2 (Type-A) x 2, USB 3.2 Gen 2 (Type-C) x 1, 10-pin USB 2.0 x 2/UART x 1
  • Audio Jack x 1 (Line out + Mic in)
  • 40-pin GPIO x 1
  • 12V DC-in
  • TPM 2.0
Download
